A333 Steel pipe
ASTM A333 Low Temperature Pipe is a type of carbon steel pipe designed to be used in low-temperature applications. A333 pipe is furnished to nine different grades designated by numbers 1, 3, 4, 6, 7, 8, 9, 10, & 11. We are a professional steel pipe manufacturer. Here support large-volume products to be shipped at factory prices. Also support testing and provide samples. Get a quote!
We supply A333 steel pipes of different grades, such as A333 Grade1 / A333 Grade 3 / A333 Grade 4 / A333 Grade 6 and more for you to choose.
We Gnee have A333 steel pipes of different sizes, such as 5 inch /6 inch /2 inch and more for you to choose.
| Standard | Grade | Chemical Composition (%) | ||||||||||
| C | Si | Mn | P | S | Cr | Ni | Cu | Mo | V | Al | ||
| ASTM A333 | Grade 1 | ≤0.30 | 0.40~1.06 | ≤0.025 | ≤0.025 | |||||||
| Grade 3 | ≤0.19 | 0.18~0.37 | 0.31~0.64 | ≤0.025 | ≤0.025 | 3.18~3.82 | ||||||
| Grade 4 | ≤0.12 | 0.18~0.37 | 0.50~1.05 | ≤0.025 | ≤0.025 | 0.44~1.01 | 0.47~0.98 | 0.40~0.75 | 0.04~0.30 | |||
| Grade 6 | ≤0.30 | ≥0.10 | 0.29~1.06 | ≤0.025 | ≤0.025 | |||||||
| Grade 7 | ≤0.19 | 0.13~0.32 | ≤0.90 | ≤0.025 | ≤0.025 | 2.03~2.57 | ||||||
| Grade 8 | ≤0.13 | 0.13~0.32 | ≤0.90 | ≤0.025 | ≤0.025 | 8.40~9.60 | ||||||
| Grade 9 | ≤0.20 | 0.40~1.06 | ≤0.025 | ≤0.025 | 1.60~2.24 | 0.75~1.25 | ||||||
| Grade 10 | ≤0.20 | 0.10~0.35 | 1.15~1.50 | ≤0.03 | ≤0.015 | ≤0.15 | ≤0.25 | ≤0.015 | ≤0.50 | ≤0.12 | ≤0.06 | |
| Grade 11 | ≤0.10 | ≤0.35 | ≤0.6 | ≤0.025 | ≤0.025 | ≤0.50 | 35.0~37.0 | ≤0.50 | ||||
| Standard | Grade | Tensile Strength (MPa) | Yield Point (MPa) | Elongation (%) | |
| Y | X | ||||
| ASTM A333 | Grade 1 | ≥380 | ≥205 | ≥35 | ≥25 |
| Grade 3 | ≥450 | ≥240 | ≥30 | ≥20 | |
| Grade 4 | ≥415 | ≥240 | ≥30 | ≥16.5 | |
| Grade 6 | ≥415 | ≥240 | ≥30 | ≥16.5 | |
| Grade 7 | ≥450 | ≥240 | ≥30 | ≥22 | |
| Grade 8 | ≥690 | ≥515 | ≥22 | ||
| Grade 9 | ≥435 | ≥315 | ≥28 | ||
| Grade 10 | ≥550 | ≥450 | ≥22 | ||
| Grade 11 | ≥450 | ≥240 | ≥18 | ||
| Grade | The lowest temperature for strike test | |
| °F | °C | |
| ASTM A333 Grade 1 | -50 | -45 |
| ASTM A333 Grade 3 | -150 | -100 |
| ASTM A333 Grade 4 | -150 | -100 |
| ASTM A333 Grade 6 | -50 | -45 |
| ASTM A333 Grade 7 | -100 | -75 |
| ASTM A333 Grade 8 | -320 | -195 |
| ASTM A333 Grade 9 | -100 | -75 |
| ASTM A333 Grade 10 | -75 | -60 |
Gnee supplies A333 Grade 6 steel pipe in large quantities that you need at factory prices. Widely used in oil, natural gas and other fields.
- Size Range:1/2” NB to 36” NB
- Thickness:SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules
- Applications:Oil Refineries, Petrochemicals, Power Generation (Nuclear/Thermal), Steel, Sugar, Boiler Equipments, Pressure Vessels and General Engineering Purposes
- End: Plain End, Beveled End, Treaded
- Outside Coating: Black Painting, Anti-Corrosion Oil, Galvanised Finish, Finish as per customer Requirements
- Provide Test Report:Non Destructive Test Reports,Chemical Test Reports, Mechanical Test Reports,Visual Inspection Reports, Third Party Inspection Reports, other test reports are also available.
| Compositions | Data |
| Carbon(max.) | 0.30 |
| Manganese | 0.29-1.06 |
| Phosphorus(max.) | 0.025 |
| Sulfur(max.) | 0.025 |
| Silicon | … |
| Nickel | … |
| Chromium | … |
| Other Elements | … |
| Properties | Data |
| Tensile strength, min, (MPa) | 415 Mpa |
| Yield strength, min, (MPa) | 240 Mpa |
| Elongation, min, (%), L/T | 30/16.5 |
In addition, our A333 pipe has been successfully exported to more than 60 countries such as Vietnam, Malaysia, Indonesia, Pakistan, UAE, and South Korea, etc. Many regular customers visit our company and factory and make multiple orders.
Gnee can provide the following measurement services for ASTM A333 pipe:
1. Dimensional measurement: Measure the dimensional parameters such as length, width, and thickness by measuring instruments to ensure the pipe is qualified and meets the design requirements.
2. Surface measurement: Measure parameters such as flatness, unevenness, and surface roughness of the A333 pipe surface to help ensure that the quality and surface state of the pipe meet the requirements.
3. Thickness measurement: Use a thickness measuring instrument to accurately measure the thickness of the A333 pipe to ensure that it meets the design requirements.
4. Material measurement: Use material analysis instruments to measure the chemical composition and mechanical properties of the product to ensure that the quality and performance meet the requirements.
5. Bending and Deformation Measurements:The degree of bending and deformation of the steel pipe is measured and monitored by using tools such as bending measuring instruments and displacement sensors to ensure that it is within the allowable range.
Gnee can customize the size and shape of steel pipes for your project according to specific project needs. The custom design of the A333 pipe is carried out by a professional engineer and design team. Based on the requirements and constraints of the project, they will use calculation and simulation tools, combined with experience and technical knowledge, to optimize the steel pipe design to meet the specific needs of your engineering.
● According to the strength requirements of structural design, adjust the thickness, width, and length of A333 steel pipes.
● The shape of the steel pipe can be designed according to the characteristics of the project.
● If you consider the convenience of installation and maintenance, we can also add openings for easy operation in the design for areas that require frequent maintenance.
Purchasing Gnee A333 steel pipe can provide the following deep processing services. We can customize according to the specific needs of customers to meet the requirements.
Cutting service: A333 steel pipe can be custom cut to obtain the desired shape and size according to the needs of customers. For example, flame cutting, plasma cutting, laser cutting, etc., can cut steel pipes into required blocks, special-shaped parts.
Bending and forming: A333 steel pipes are bent and formed by stress application and appropriate processes to obtain the desired shape.
Welding service: A333 steel pipe can be subjected to various types of welding services, including manual arc welding, gas-shielded welding, laser welding, etc.
Turning and machining of holes: Turning and machining of holes in A333 steel pipes by using machining equipment. These processes produce smooth surfaces, precise holes and threads to meet specific assembly requirements.
Surface treatment: In order to improve the corrosion resistance and aesthetics of the steel pipe, surface treatment can be carried out. This includes methods such as spraying, hot-dip galvanizing, electroplating, etc. to add a protective layer and provide corrosion resistance.
Gnee A333 steel pipe can provide the following testing services through third-party testing agencies. These third-party testing services can provide independent, objective verification that A333 pipes comply with relevant standards and regulations.
Material chemical composition analysis: Through chemical composition analysis, determine whether the composition of the steel pipe meets the standard requirements.
Mechanical performance test: Mechanical performance test includes tensile test, impact test, bending test, etc., which are used to determine whether the mechanical properties such as strength, toughness and ductility of products meet the specified requirements.
Metallographic testing: Through metallographic testing, check the structure, grain size, non-metallic inclusions, etc. of A333 steel pipes to evaluate their quality and performance.
Corrosion performance test: Through the corrosion performance test, evaluate the corrosion resistance of A333 pipes, including salt spray corrosion resistance, chemical corrosion resistance, etc.
Hardness test: Hardness test is used to measure the hardness of A333 steel pipe, and its strength and wear resistance can be evaluated according to the hardness value.
Ultrasonic flaw detection: Ultrasonic flaw detection is used to detect internal defects of pipes, such as cracks, pores, inclusions, etc.
